6.1.3.5 Monitoring events
Event view contains a list of events produced by the application configuration. Each
event takes one view area. The header area shows the currently viewed event index
and the total amount of the events. The most recent event is always first.
1. Select Main Menu/Events.
2.
Press to view the first event.
Date, time, device description, object description and event text elements of the
event are shown.
3.
Press or to scroll the view.
A071148 V2 EN
Figure 49: Monitoring events
6.1.4 Remote monitoring
The IED supports comprehensive remote monitoring.
6.1.4.1 Operating IED remotely
Use the PCM600 tool or WHMI to:
• Read maintenance record and version log.
• Analyze disturbance record data.
• Create disturbance records.
• Read IED values.
For more information, see PCM600 documentation.
