7.14.2 Functionality
Conventional protection functions can not detect the broken conductor condition. Broken
conductor check BRCPTOC (46) function, consisting of continuous phase selective
current unsymmetrical check on the line where the IED is connected will give alarm or trip
at detecting broken conductors.
7.14.3 Function block
ANSI09000277-1-en.vsd
BRCPTOC (46)
I3P*
BLOCK
TRIP
PICKUP
ANSI09000277 V1 EN
Figure 130: BRCPTOC (46) function block
7.14.4 Signals
Table 157: BRCPTOC (46) Input signals
Name Type Default Description
I3P GROUP
SIGNAL
- Three phase group signal for current inputs
BLOCK BOOLEAN 0 Block of function
Table 158: BRCPTOC (46) Output signals
Name
Type Description
TRIP BOOLEAN Operate signal of the protection logic
PICKUP BOOLEAN Pickup signal of the protection logic
7.14.5 Settings
Table 159: BRCPTOC (46) Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Disabled
Enabled
- - Disabled Operation Disable / Enable
Pickup_ub 50 - 90 %IM 1 50 Unbalance current operation value in percent
of max current
Pickup_PH 5 - 100 %IB 1 20 Minimum phase current for operation of
pickup_ub> in % of Ibase
tOper 0.000 - 60.000 s 0.001 5.000 Operate time delay
Section 7 1MRK 506 335-UUS A
Current protection
276
Technical manual
