11.4.7 Local remote control LOCREMCTRL
11.4.7.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Local remote control LOCREMCTRL - -
11.4.7.2 Functionality
The signals from the local HMI or from an external local/remote switch are applied via the
function blocks LOCREM and LOCREMCTRL to the Bay control QCBAY function
block. A parameter in function block LOCREM is set to choose if the switch signals are
coming from the local HMI or from an external hardware switch connected via binary
inputs.
11.4.7.3 Function block
IEC09000074_1_en.vsd
LOCREMCTRL
^PSTO1
^PSTO2
^PSTO3
^PSTO4
^PSTO5
^PSTO6
^PSTO7
^PSTO8
^PSTO9
^PSTO10
^PSTO11
^PSTO12
^HMICTR1
^HMICTR2
^HMICTR3
^HMICTR4
^HMICTR5
^HMICTR6
^HMICTR7
^HMICTR8
^HMICTR9
^HMICTR10
^HMICTR11
^HMICTR12
IEC09000074 V1 EN
Figure 188: LOCREMCTRL function block
11.4.7.4 Signals
Table 268: LOCREMCTRL Input signals
Name
Type Default Description
PSTO1 INTEGER 0 PSTO input channel 1
PSTO2 INTEGER 0 PSTO input channel 2
PSTO3 INTEGER 0 PSTO input channel 3
Table continues on next page
