14.19.3 Signals
Table 515: I103MEAS Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of service value reporting
IL1 REAL 0.0 Service value for current phase A
IL2 REAL 0.0 Service value for current phase B
IL3 REAL 0.0 Service value for current phase C
IN REAL 0.0 Service value for residual current IN
UL1 REAL 0.0 Service value for voltage phase A
UL2 REAL 0.0 Service value for voltage phase B
UL3 REAL 0.0 Service value for voltage phase C
UL1L2 REAL 0.0 Service value for voltage phase-phase AB
UN REAL 0.0 Service value for residual voltage VN
P REAL 0.0 Service value for active power
Q REAL 0.0 Service value for reactive power
F REAL 0.0 Service value for system frequency
14.19.4 Settings
Table 516: I103MEAS Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 1 Function type (1-255)
MaxIL1 1 - 99999 A 1 3000 Maximum current phase A
MaxIL2 1 - 99999 A 1 3000 Maximum current phase B
MaxIL3 1 - 99999 A 1 3000 Maximum current phase C
MaxIN 1 - 99999 A 1 3000 Maximum residual current IN
MaxUL1 0.05 - 2000.00 kV 0.05 230.00 Maximum voltage for phase A
MaxUL2 0.05 - 2000.00 kV 0.05 230.00 Maximum voltage for phase B
MaxUL3 0.05 - 2000.00 kV 0.05 230.00 Maximum voltage for phase C
MaxUL1-UL2 0.05 - 2000.00 kV 0.05 400.00 Maximum voltage for phase-phase AB
MaxUN 0.05 - 2000.00 kV 0.05 230.00 Maximum residual voltage VN
MaxP 0.00 - 2000.00 MW 0.05 1200.00 Maximum value for active power
MaxQ 0.00 - 2000.00 MVA 0.05 1200.00 Maximum value for reactive power
MaxF 45.0 - 66.0 Hz 1.0 51.0 Maximum system frequency
