11.9 Single point generic control 8 signals SPC8GGIO
11.9.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Single point generic control 8 signals SPC8GGIO - -
11.9.2 Functionality
The Single point generic control 8 signals SPC8GGIO function block is a collection of 8
single point commands, designed to bring in commands from REMOTE (SCADA) to
those parts of the logic configuration that do not need extensive command receiving
functionality (for example, SCSWI). In this way, simple commands can be sent directly
to the IED outputs, without confirmation. The commands can be pulsed or steady with a
settable pulse time.
11.9.3 Function block
SPC8GGIO
BLOCK
PSTO
^OUT1
^OUT2
^OUT3
^OUT4
^OUT5
^OUT6
^OUT7
^OUT8
IEC09000086_1_en.vsd
IEC09000086 V1 EN
Figure 222: SPC8GGIO function block
11.9.4 Signals
Table 311: SPC8GGIO Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
PSTO INTEGER 2 Operator place selection
