16.7 GOOSE function block to receive a measurand value
GOOSEMVRCV
16.7.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
GOOSE function block to receive a
measurand value
GOOSEMVRCV - -
16.7.2 Functionality
GOOSEMVRCV is used to receive measured value using IEC61850 protocol via
GOOSE.
16.7.3 Function block
IEC10000251-1-en.vsd
GOOSEMVRCV
BLOCK ^MVOUT
DATAVALID
COMMVALID
TEST
IEC10000251 V1 EN
Figure 340: GOOSEMVRCV function block
16.7.4 Signals
Table 557: GOOSEMVRCV Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
Table 558: GOOSEMVRCV Output signals
Name
Type Description
MVOUT REAL Measurand value output
DATAVALID BOOLEAN Data valid for measurand value output
COMMVALID BOOLEAN Communication valid for measurand value output
TEST BOOLEAN Test output
