13.4.1.4 PULSETIMER function block
Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
PULSETIMER function block PULSETIMER - -
Functionality
The pulse function can be used, for example for pulse extensions or limiting of operation
of outputs. The PULSETIMER has a settable length.
Function block
PULSETIMER
INPUT OUT
IEC09000291-1-en.vsd
IEC09000291 V1 EN
Figure 263: PULSETIMER function block
Signals
Table 379: PULSETIMER Input signals
Name
Type Default Description
INPUT BOOLEAN 0 Input signal
Table 380: PULSETIMER Output signals
Name
Type Description
OUT BOOLEAN Output signal
Settings
Table 381: PULSETIMER Non group settings (basic)
Name
Values (Range) Unit Step Default Description
t 0.000 - 90000.000 s 0.001 0.010 Pulse time length
