17.2 Time synchronization
17.2.1 Functionality
The time synchronization source selector is used to select a common source of absolute
time for the IED when it is a part of a protection system. This makes it possible to compare
event and disturbance data between all IEDs in a station automation system.
Micro SCADA OPC server should not be used as a time synchronization
source.
17.2.2 Time synchronization TIMESYNCHGEN
17.2.2.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Time synchronization TIMESYNCHGE
N
- -
17.2.2.2 Settings
Table 574: TIMESYNCHGEN Non group settings (basic)
Name
Values (Range) Unit Step Default Description
CoarseSyncSrc Disabled
SNTP
DNP
IEC60870-5-103
-
- Disabled Coarse time synchronization source
FineSyncSource Disabled
SNTP
IRIG-B
-
- Disabled Fine time synchronization source
SyncMaster Disabled
SNTP-Server
- - Disabled Activate IED as synchronization master
17.2.3 Time synchronization via SNTP
17.2.3.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Time synchronization via SNTP SNTP - -
