ABB REL650 series - Function Block

14.21.2 Function block
I103AR
BLOCK
16_ARACT
128_CBON
130_BLKD
IEC10000289-2-en.vsd
IEC10000289 V2 EN
Figure 326: I103AR function block
14.21.3 Signals
Table 519: I103AR Input signals
Name Type Default Description
BLOCK BOOLEAN 0 Block of status reporting
16_ARACT BOOLEAN 0 Information number 16, auto-recloser active
128_CBON BOOLEAN 0 Information number 128, circuit breaker on by auto-
recloser
130_BLKD BOOLEAN 0 Information number 130, auto-recloser blocked
14.21.4 Settings
Table 520: I103AR Non group settings (basic)
Name
Values (Range) Unit Step Default Description
FunctionType 1 - 255 - 1 1 Function type (1-255)
14.22 Function status ground-fault for IEC 60870-5-103
I103EF
14.22.1 Functionality
I103EF is a function block with defined functions for ground fault indications in monitor
direction. This block includes the FunctionType parameter, and the information number
parameter is defined for each output signal.
