is copied to TIME output. Quality bits in common part and indication part of inputs
signal is copied to the corresponding quality output.
13.4.1.2 OR function block
Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
OR Function block OR - -
Functionality
The OR function is used to form general combinatory expressions with boolean variables.
The OR function block has six inputs and two outputs. One of the outputs is inverted.
Function block
OR
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
INPUT6
OUT
NOUT
IEC09000288-1-en.vsd
IEC09000288 V1 EN
Figure 261: OR function block
Signals
Table 375: OR Input signals
Name
Type Default Description
INPUT1 BOOLEAN 0 Input signal 1
INPUT2 BOOLEAN 0 Input signal 2
INPUT3 BOOLEAN 0 Input signal 3
INPUT4 BOOLEAN 0 Input signal 4
INPUT5 BOOLEAN 0 Input signal 5
INPUT6 BOOLEAN 0 Input signal 6
Section 13 1MRK 506 335-UUS A
Logic
544
Technical manual
