14.1.6 Voltage sequence measurement VMSQI
14.1.6.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Voltage sequence measurement VMSQI
U1, U2, U0
SYMBOL-TT V1 EN
-
14.1.6.2 Function block
The available function blocks of an IED are depending on the actual hardware (TRM) and
the logic configuration made in PCM600.
ANSI08000224-1-en.vsd
VMSQI
V3P* 3V0
3V0RANG
3V0ANGL
V1
V1RANG
V1ANGL
V2
V2RANG
V2ANGL
ANSI08000224 V1 EN
Figure 283: VMSQI function block
14.1.6.3 Signals
Table 440: VMSQI Input signals
Name
Type Default Description
V3P GROUP
SIGNAL
- Three phase group signal for voltage inputs
Table 441: VMSQI Output signals
Name
Type Description
3V0 REAL 3U0 Amplitude
3V0RANG INTEGER 3V0 Magnitude range
3V0ANGL REAL 3U0 Angle
V1 REAL U1 Amplitude
Table continues on next page
