11.5.10.6 Settings
The function does not have any settings available in Local HMI or Protection and Control
IED Manager (PCM600).
11.5.11 Position evaluation POS_EVAL
11.5.11.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Position evaluation POS_EVAL - -
11.5.11.2 Functionality
Position evaluation (POS_EVAL) function converts the input position data signal
POSITION, consisting of value, time and signal status, to binary signals OPENPOS or
CLOSEPOS.
The output signals are used by other functions in the interlocking scheme.
11.5.11.3 Function block
POS_EVAL
POSITION OPENPOS
CLOSEPOS
IEC09000079_1_en.vsd
IEC09000079 V1 EN
Figure 217: POS_EVAL function block
11.5.11.4 Logic diagram
POS_EVAL
POSITION OPENPOS
CLOSEPOS
IEC08000469-1-en.vsd
Position including quality
Open/close position of
switch device
IEC08000469-1-EN V1 EN
Only the value, open/close, and status is used in this function. Time information is not
used.
1MRK 506 335-UUS A Section 11
Control
471
Technical manual
