17.14.3 Settings
Table 606: FTPACCS Non group settings (basic)
Name
Values (Range) Unit Step Default Description
PortSelection None
Front
LAN1
Front+LAN1
-
- Front+LAN1 Port selection for communication
SSLMode FTP+FTPS
FTPS
- - FTPS Support for AUTH TLS/SSL
TCPPortFTP 1 - 65535 - 1 21 TCP port for FTP and FTP with Explicit SSL
TCPPortFTPS 1 - 65535 - 1 990 TCP port for FTP with Implicit SSL
17.15 Authority status ATHSTAT
17.15.1 Identification
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Authority status ATHSTAT - -
17.15.2 Functionality
Authority status ATHSTAT function is an indication function block for user log-on
activity.
User denied attempt to log-on and user successful log-on are reported.
17.15.3 Function block
ATHSTAT
USRBLKED
LOGGEDON
IEC09000235_en_1.vsd
IEC09000235 V1 EN
Figure 359: ATHSTAT function block
Section 17 1MRK 506 335-UUS A
Basic IED functions
780
Technical manual
