Table 25: ZQMPDIS (21) Output signals
Name Type Description
TRIP BOOLEAN General trip
TR_A BOOLEAN Trip signal for L1
TR_B BOOLEAN Trip signal for L2
TR_C BOOLEAN Trip signal for L3
TRZ1 BOOLEAN Trip signal Zone1
TRZ2 BOOLEAN Trip signal Zone2
TRZ3 BOOLEAN Trip signal Zone3
TRZ4 BOOLEAN Trip signal Zone4
TRZ5 BOOLEAN Trip signal Zone5
PICKUP BOOLEAN Pickup
PU_A BOOLEAN Start signal for L1
PU_B BOOLEAN Start signal for L2
PU_C BOOLEAN Start signal for L3
PU_Z1 BOOLEAN Start signal Zone1
PU_Z2 BOOLEAN Start signal Zone2
Z3_PU BOOLEAN Start signal Zone3
Z4_PU BOOLEAN Start signal Zone4
Z5_PU BOOLEAN Start signal Zone5
6.1.5 Settings
Table 26: ZQMPDIS (21) Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Disabled
Enabled
- - Disabled Disable/Enable Operation
CvtFltr Disabled
Enabled
- - Enabled Enable CVT Filtering
LineAng 0.00 - 90.00 Deg 0.01 80.00 Line impedance angle in degrees, common for
all zones
KNMag 0.000 - 3.000 - 0.001 0.000 Common ground compensation factor
magnitude for Zone 2, 3, 4 & 5
KNAng -180 - 180 Deg 1 -15 Common ground compensation factor angle
for Zone 2, 3, 4 & 5
IMinPUPG 10 - 30 %IB 1 15 Minimum operating phase current for phase to
ground loops, % of IBase
IMinPUPP 10 - 30 %IB 1 15 Minimum operating phase current for phase to
phase loops, in % of IBase
Table continues on next page
1MRK 506 335-UUS A Section 6
Impedance protection
