14.2.4 Signals
Table 451: CNTGGIO Input signals
Name
Type Default Description
BLOCK BOOLEAN 0 Block of function
COUNTER1 BOOLEAN 0 Input for counter 1
COUNTER2 BOOLEAN 0 Input for counter 2
COUNTER3 BOOLEAN 0 Input for counter 3
COUNTER4 BOOLEAN 0 Input for counter 4
COUNTER5 BOOLEAN 0 Input for counter 5
COUNTER6 BOOLEAN 0 Input for counter 6
RESET BOOLEAN 0 Reset of function
Table 452: CNTGGIO Output signals
Name Type Description
VALUE1 INTEGER Output of counter 1
VALUE2 INTEGER Output of counter 2
VALUE3 INTEGER Output of counter 3
VALUE4 INTEGER Output of counter 4
VALUE5 INTEGER Output of counter 5
VALUE6 INTEGER Output of counter 6
14.2.5 Settings
Table 453: CNTGGIO Group settings (basic)
Name
Values (Range) Unit Step Default Description
Operation Disabled
Enabled
- - Disabled Disable/Enable Operation
14.2.6 Monitored data
Table 454: CNTGGIO Monitored data
Name
Type Values (Range) Unit Description
VALUE1 INTEGER - - Output of counter 1
VALUE2 INTEGER - - Output of counter 2
VALUE3 INTEGER - - Output of counter 3
Table continues on next page
1MRK 506 335-UUS A Section 14
Monitoring
607
Technical manual
