53SCU200 INSITE ENERGY MANAGEMENT SYSTEM
• I/O modules
Add
Add and assign new I/O module
Create a new I/O module Modbus
ID and then assign it to the physical
module by clicking the pushbutton
of the I/O module (Note: Wait for
confirmation before assigning the
next I/O module).
Add new I/O Modules (automatically)
Create a new I/O Module Modbus ID
by automatically assigning it to the
physical module randomly (Note:
wait for confirmation pop-up window
before configuring the modules
detected).
Assign I/O module (already added)
If a I/O module ID has already been
created but is unassigned, it is
possible to assign it to the physical
I/O module by clicking the pushbutton
of the I/O module.
Add new I/O module (no assigning)
Create a new I/O module ID without
assigning it to the physical I/O
module.
Identify
Clicking the pushbutton of the current I/O module allows to display the I/O
module Modbus ID number.
Change ID
Select the current Modbus ID number of the current I/O module and define the
new Modbus ID number of it.
Remove all
Remove all I/O modules and their settings. To remove one single I/O module,
click on the “X” symbol under the Action column.
