56 SCU200 INSITE ENERGY MANAGEMENT SYSTEM
• Modbus RTU devices
In this section it is possible to add Modbus RTU devices connected to the SCU200.
It is possible to download device descriptor with registers that was configured or upload previously
prepared/configured descriptor.
Maximum no. Registers per single device is 128. The maximum length of register (variable) name is 128.
Only ASCII characters are allowed.
Add
Device model
Select the predefined device model, select “Custom device” to
configure registers manually. For predefined device models it is
not possible to edit registers or upload descriptor.
Modbus ID Set the Modbus ID of the device (between 33 and 48)
Name Set the name of the device
Device category Defines the category of the device.
Baud rate Select the baud rate among the ratings (from 1200 to 115200)
Byte size Select the Byte size among the ones available (4,6, 7 or 8)
Parity Select the parity among the ones available (None, Odd, Even)
Stop bits Select the Stop bit among the ones available (1 or 2)
