4.2 Exhaust gas temperature before turbine
CAUTION
Factors influencing replacement intervals
Operation above the operating limits defined on the rating plate can shorten
the recommended replacement intervals considerably.
 Measure exhaust gas temperature upstream of turbine.
 Comply with operating limits on rating plate.
 Definition and explanations concerning rating plate: refer to chapter 2 of Operation Manual /
Safety.
 Operating limits: refer to chapter 3 of Operation Manual / Safety data sheet or examine
rating plate.
4.3 Turbocharger speed
4.3.1 Introduction
A speed measuring system enables the constant monitoring of the turbocharger speed.
CAUTION
Do not strain cables
If you pull the speed measurement cables too hard, contacts can be pulled
out.
 Do not strain the speed measurement cables by pulling.
CAUTION
Machine damage
Operation above the operating limits defined on the rating plate can shorten
the recommended replacement intervals considerably and cause machine
damage.
 Measure turbocharger speed.
 Comply with operating limits on rating plate.
 Definition and explanations concerning rating plate: refer to chapter 2 of Operation Manual /
Safety.
 Operating limits: refer to chapter 3 of Operation Manual / Safety data sheet or examine
rating plate.
If no speed measurement system is present, the system below can be ordered from an ABB
Turbocharging Service Station (see chapter Ordering spare parts [➙ 93]).
