Table 15.3: Process Value Registers (MODBUS)
(Continued)
Register Addresses
(decimal)
Scanner Process Values
5111 LoFlame temperature high byte
5111 HiFlame temperature low byte
5112 LoIntensity for sensor 1, if safe as second Flame-relay
5112 HiFlicker-Frequency for sensor 1, if safe as second Flame-relay
5113 LoAC-Amplitude for sensor 1, if safe as second Flame-relay
5113 HiQuality for sensor 1, if safe as second Flame-relay
5114 LoCollected data can be sent to FEX (0 = no, 1 = yes, and 2 = stop)
5114 HiSpare
5115 LoDTC version flag (0x0a = Rev 04L and 0x0e = Rev 004)
5115 HiSpare
5118 LoSpare (also spares 5116 and 5117)
5118 HiSensor type (IR, UV, and DUAL)
Holding Registers (Programmable Parameter Registers)
The holding registers provide the ability to read/set the scanner parameter values to/from
a MODBUS master.
Change these values only using the Flame Explorer tool. There is an automatic
procedure that performs safety operations in the Flame Explorer tool. This cannot
be replicated (and MUST not be replicated) on a generic MODBUS master.
Table 15.4: Channel Configuration Parameter Registers (MODBUS)
Register AddressesScanner Configuration Parameters
4000-4004Reserved for ABB
4005MODBUS address on serial #1
4006MODBUS address on serial #2
4007Sensor type (single or dual)
4008Flame logic on dual sensor (OR/AND)
4009Flame-relay usage (Safe-relay, second Flame-relay, Quality-relay, and
Temperature-relay)
4010Operating mode
8VZZ005286 B 102
15 Serial Interfaces
15.2 MODBUS Protocol
