Abov E-OCD II User Manual

Debugger Software (for Microsoft Windows) E-OCD II Debugger User’s Manual
70
2) Remove global variable ( )
: Remove global symbols from this view. This button is disabled when the symbol information
is empty.
Figure 3-82 Global Variable Remove Dialog
You can remove a global symbol in one of the following ways:
 Double-click on the symbol name you want to remove.
 Select the variable and click Remove.
 Type in the symbol name and click the Remove.
3) Values
: In this view, values are displayed as hexadecimal, decimal, or binary numbers.
 Bit variables: 0 or 1
 1-byte variables: Hexadecimal, decimal, or binary numbers
 2- or 4-byte variables: Hexadecimal or decimal numbers
 Arrays/pointers/structures: 2-byte values. These are pointer values and not data.
