Appendix: E-OCD II Isolator Interface E-OCD II Debugger User’s Manual
90
6 Appendix: E-OCD II Isolator Interface
The E-OCD II isolator interface is designed to prevent power collision between the Host PC and target
hardware:
 The operating voltage ranges between 2.8–5.5 V. This is slightly higher than the regular
OCD/OCD II interfaces.
 The rest are the same as the OCD and OCD II interfaces.
Figure 6-1 E-OCD II Isolator
Caution :
Be cautions when using a transformer-less target power supply
