Abov E-OCD II User Manual

E-OCD II Debugger User’s Manual Debugger Software (for Microsoft Windows)
65
3.4.9 Source View
This view shows a text file or source code file with each line numbered. The data displayed in the view
is not editable, and each tab shown is sized as four spaces.
If the Symbol file has already been loaded, the Source file will display the line numbers and real
addresses combined as shown in the screenshot below.
Figure 3-74 Source View Window
 If you double click the left mouse button on an address, the disassemble view is refreshed
to show data in that address.
 Lines assigned a program counter break are highlighted in blue.
 Right-clicking opens a sub-menu shown below:
Figure 3-75 Sub Menu
The shortcut keys are T, N, and G.
