15. Technical data
RFID proximity keyfob reader
Operating frequency
13.56 MHz
In accordance with:
EN 300 330-2
Special features Individual identication
Connections
L N
Mains connection
110V/230VAC, 50/60Hz, (85-265VAC, 50/60Hz)
L – line, single phase (black or brown)
– protective earth (yellow/green)
N – neutral (blue)
- DC IN +
13.8 V
External PSU input
13.8VDC, external PSU at least 1.7A
See Power supply section for more details
0V 12V
AUX
Voltage output
13.8VDC up to 700mA
Maximum output residual ripple (ripple voltage):
0.2Vp-p
Aux output fault triggered at 11.5V, ok from 12.0V
See Power supply section for more details
+BATT1 ,+BATT2 Battery polymer lithium ion, 7.4V, 2500mAh
OP 301, OP 302
Relay output
Potential-free changeover contact NO/C/NC
Max. contact capacity: 500mA @ 24VAC rms or 30VDC
OP 303, OP 304
Transistor output
Open-drain
Max. contact capacity: 500mA @ 13.8VDC
TR
A negative tamper input
The input is switched to the inactive low state (ground potential)
by the connected siren. The threshold voltages are > 4V for active
and < 3.6V for inactive.
TRB
A negative fault input
The input is switched to the inactive low state (ground potential)
by the connected siren. The threshold voltages are > 4V for active
and < 3.6V for inactive.
10/100 LAN
Ethernet/LAN
Cat5e patch cable, RJ45 male
Connector at each end, suitable for 10/100Base-T
USB TYPE-B
USB Mini-B connector for alarm panel
USB-A connector for PC
Max. length 3m
