15. Technical data
Fuses
Mains fuse (AC in)
Miniature fuse (micro fuse)
removable
Name T1AL250V
Characteristic T = slow blow
Operating current 1 A
Breaking capacity L = low
Operating voltage 250 V
Design Glass tube 5x20mm
Wireless signal transmission
Operating frequency
868.6625MHz
In accordance with:
EN50131-5-3 Grade2
EN 300 220-1 V.2.1.1
EN 300 220-2 V.2.1.1
EN 300 220-3 V.1.1.1
Frequency band reserved for applications in the security zone
Modulation FM
Bandwidth
+/- 10kHz
Narrow band, 25kHz channel separation
Transmission power 10 mW
Antenna Integrated duplex antenna technology
Range
Indoors: approximately 30m
depending on environmental factors
Outdoors: approximately 100m
Special features Individual identication
