INPUT OUTPUT
MODEL (240 Vac, 50 - 60 Hz) (0 - 230 Vac)
NOMINAL NOMINAL
MODEL CURRENT CURRENT
NUMBER RATED INPUT (AMPS) POWER (AMPS) POWER
(NOT E 1)
HP PHASE
(NOT E 2)
(KVA)
(NOT E 2)
(KVA)
M1205S 0.5 1 5.0 1.2 2.2 0.9
M1205 0.5 3 2.7 1.1 2.2 0.9
M1210S 1 1 9.0 2.2 4.0 1.6
M1210 1 3 4.8 2.0 4.0 1.6
M1215S 1.5 1 11.6 2.8 5.2 2.1
M1215 1.5 3 6.2 2.6 5.2 2.1
M1220S 2 1 14.9 3.6 6.8 2.7
M1220 2 3 8.1 3.4 6.8 2.7
M1230S 3 1 21.0 5.0 9.6 3.8
M1230 3 3 11.3 4.7 9.6 3.8
M1250 5 3 17.7 7.4 15.2 6.1
M1275 7.5 3 26.0 10.6 22.0 8.8
M12100 10 3 32.0 13.2 28.0 11.2
M12150 15 3 48.0 19.8 42.0 16.7
M12200 20 3 61.0 25.3 54.0 21.5
M12250 25 3 77.0 32.0 68.0 27.1
M12300 30 3 90.0 37.6 80.0 31.9
NOTE 1: See Section 3.0 for model number breakdown.
NOTE 2: For 200 Vac input voltage on THREE PHASE MODELS ONLY, multiply the
input and output current ratings by 1.15 and the output voltage by 0.87.
NOTE 3: See Section 8.0 for recommended fuse type.
M1200 SERIES RATINGS
