AC Tech MC1000 series - 5.0 MC1000 Ratings; M1100 Series Ratings

8
INPUT
INPUTINPUT
INPUT OUTPUT
OUTPUTOUTPUT
OUTPUT
MODEL
MODELMODEL
MODEL (240 / 120 Vac, 50 - 60 Hz)
(240 / 120 Vac, 50 - 60 Hz)(240 / 120 Vac, 50 - 60 Hz)
(240 / 120 Vac, 50 - 60 Hz) (0 - 230 Vac)
(0 - 230 Vac)(0 - 230 Vac)
(0 - 230 Vac)
NOMINAL NOMINAL
MODEL CURRENT CURRENT
NUMBER RATED INPUT (AMPS) POWER (AMPS) POWER
(NOTE 1)
HP PHASE
(NOTE 2)
(KVA)
(NOTE 2)
(KVA)
M1103S 0.25 1 3.0 / 6.0 0.72 1.4 0.56
M1105S 0.5 1 4.6 / 9.2 1.1 2.2 0.88
M1110S 1 1 8.1 / 16.2 1.9 4.0 1.6
M1115S 1.5 1 10.4 / 21 2.5 5.2 2.1
NOTE 1: See Section 3.0 for model number breakdown.
NOTE 2: The higher current rating is for 120 Vac input and the lower current rating is
for 240 Vac input.
NOTE 3: See Section 8.0 for recommended fuse type.
M1100 SERIES RATINGS
5.0 MC1000 RATINGS
The following tables indicate the input and output ratings of the MC1000 Series
drive.
NOTE: The output current ratings are based on operation at carrier frequencies
of 8 kHz and below. At full ambient temperature, operation at carrier frequencies
above 8 kHz require derating the drive by multiplying the output current rating
by the following factors: 0.94 at 10 kHz, 0.89 at 12 kHz, and 0.83 at 14 kHz.
Refer to Parameter 23 - CARRIER in Section 18.0 - DESCRIPTION OF
PARAMETERS.
