AC Tech MC1000 series - 3 Mc1000 Model Designation Code

3
M1 4 50 B P
Series:
M1 = MC1000 Series Variable Speed AC Motor Drive
Input Voltage:
1
2
4
5
= 240/120 Vac (For 110, 115, 120, 230 and 240 Vac; 50 or 60 Hz)
= 240/200 Vac (For 208 and 240 Vac; 50 or 60 Hz)
= 480/400 Vac (For 380, 415, 440, 460 and 480 Vac; 50 or 60 Hz)
= 590/480 Vac (For 440, 460, 480, 575 and 600 Vac; 50 or 60 Hz)
Horsepower:
03
05
10
15
20
30
= ¼ Hp
= ½ Hp
= 1 Hp
= 1½ Hp
= 2 Hp
= 3 Hp
50 / 51
75
100
150
200
250
= 5 Hp
= 7½ Hp
= 10 Hp
= 15 Hp
= 20 Hp
= 25 Hp
300
400
500
600
= 30 Hp
= 40 Hp
= 50 Hp
= 60 Hp
Input:
S = Single phase input.
No character indicates three phase input.
Enclosure Type:
A
B
C
D
E
= Chassis - Open Enclosure with Door Removed
= NEMA 1 - General Purpose, vented
= NEMA 4 - Water-tight and Dust-tight
= NEMA 12 - Dust-tight and Drip-tight
= NEMA 4X - Water-tight, Dust-tight and Corrosion Resistant
Standard Options:
H
J
K
= Additional Form “C” Relay circuit board
= Dynamic Braking circuit board
= Additional Relay & Dynamic Braking board (not available on all HP sizes – consult factory)
No character when this type of option is not specified.
Interface Options:
P
Q
R
= Remote Keypad Assembly
= No Keypad
= No Keypad & No Display
No character when this type of option is not specified.
3.0 MC1000 MODEL DESIGNATION CODE
The model number of an MC1000 Series drive gives a full description of the
basic drive unit (see example below).
EXAMPLE: M1450BP
(MC1000, 480 Vac, 5 HP, Type 1 Enclosure, with a Remote Keypad Assembly)
