49
INPUT LINE VOLTAGE SELECTION
RATED INPUT
RATED INPUTRATED INPUT
RATED INPUT INPUT
INPUTINPUT
INPUT ACTUAL INPUT
ACTUAL INPUTACTUAL INPUT
ACTUAL INPUT PARAM.
PARAM.PARAM.
PARAM.
MODEL
MODELMODEL
MODEL VOLTAGE
VOLTAGEVOLTAGE
VOLTAGE PHASE
PHASEPHASE
PHASE VOLTAGE
VOLTAGEVOLTAGE
VOLTAGE SETTING
SETTINGSETTING
SETTING
M1100S 240 / 120 Vac 1 220 - 240 Vac HIGH
240 / 120 Vac 1 110 - 120 Vac HIGH
M1200(S) 240 Vac 1 220 - 240 Vac HIGH
240 / 200 Vac 3 220 - 240 Vac HIGH
240 / 200 Vac 3 200 - 208 Vac LOW
M1400 480 / 400 Vac 3 460 - 480 Vac HIGH
480 / 400 Vac 3 380 - 415 Vac LOW
M1500 590 / 480 Vac 3 575 - 600 Vac HIGH
590 / 480 Vac 3 460 - 480 Vac LOW
18.0 DESCRIPTION OF PARAMETERS
0 LINE VOLTS (LINE VOLTAGE)
This parameter calibrates the drive for the correct input voltage, and can be set to
AUTO, HIGH, or LOW.
When set to AUTO, the drive measures the DC bus voltage when power is
applied and automatically calibrates itself according to the measured value (DC
bus voltage is equal to input voltage multiplied by 1.4).
This parameter can also be set “manually”, using the HIGH or LOW settings. For
actual line voltages of 230/240 Vac (on 240/200 Vac models), 460/480 Vac (on 480/
400 Vac models), or 575/590 Vac (on 590/480 Vac models), set this parameter to
HIGH. Also use the HIGH setting for 240/120 Vac single-phase input models.
Refer to the table below.
For actual line voltages of 200/208 Vac (on 240/200 Vac models), 380/415 Vac (on
480/400 Vac models), or 460/480 Vac (on 590 Vac models), set this parameter to
LOW. Refer to the table below.
1-4 SPEED #1- #4 (PRESET SPEEDS #1, #2, #3, AND #4)
PRESET SPEEDS are only active when the drive is in AUTO mode, and are
activated via contact closures between terminal TB-2 and terminals TB-13A, TB-
13B, and TB-13C. These terminals must be programmed as preset speed selects
using Parameters 47 - 49: TB13A, TB13B, and TB13C.
