2
2.0 MC1000 SPECIFICATIONS
Storage Temperature -20° to 70° C
Ambient Operating Temperature Chassis -10° to 55° C
(With 2.5, 6, and 8 kHz carrier, Type 1 (IP 31) -10° to 50° C
derate for higher carriers) Type 4 (IP 65) -10° to 40° C
Type 12 (IP 54) -10° to 40° C
Ambient Humidity Less than 95% (non-condensing)
Altitude 3300 feet (1000 m) above sea level
without derating
Input Line Voltages 240/120 Vac, 240/200 Vac,
480/400 Vac, and 590/480 Vac
Input Voltage Tolerance +10%, -15%
Input Frequency Tolerance 48 to 62 Hz
Output Wave Form Sine Coded PWM
Output Frequency0-120 Hz, Optional up to 1000 Hz
Carrier Frequency 2.5 kHz to 14 kHz
Frequency Stability + 0.00006% / °C
Service Factor 1.00
Efficiency > 97% throughout speed range
Power Factor (displacement) > 0.96
Overload Current Capacity 150% of output rating for 60 seconds
180% of output rating for 30 seconds
Speed Reference Follower 0-10 VDC, 4-20 mA
Control Voltage 15 VDC
Analog Outputs 0 - 10 VDC, or 2 - 10 VDC
Proportional to speed and load
Digital Outputs Form C relay: 2 A at 28 VDC or
120 Vac
Open-collector outputs: 40 mA at
30 VDC
