13.2 MC1000 DISPLAY
The following describes the possible display configurations for the MC1000
Series drive.
13.2.1 MC1000 DISPLAY IN STOP MODE
When the drive is in the STOP mode, there are three possible displays. The first
is the SPEED display, which looks like this:
NOTE: See Parameter 31 - UNITS for the SPEED UNITS display options.
Pressing the ENTER key will change the display from the SPEED indication to
the % LOAD indication:
Pressing the ENTER key again will change the display from the % LOAD indication
to the VAC (motor voltage) indication:
Pressing ENTER again will change the display back to the SPEED indication.
STOP > 60.00 HZ
DRIVE
STATUS
SPEED
SETPOINT
SPEED
UNITS
DIRECTION
(FORWARD)
STOP > 0 VAC
DRIVE
STATUS
MOTOR
VOLTAGE
DIRECTION
(FORWARD)
STOP > 0% LOAD
DRIVE
STATUS
PERCENT
LOAD
DIRECTION
(FORWARD)
