46
PARAMETER MENU
PARAM.
PARAM.PARAM.
PARAM. PARAMETER
PARAMETERPARAMETER
PARAMETER RANGE OF
RANGE OFRANGE OF
RANGE OF FACTORY
FACTORYFACTORY
FACTORY
NUMBER
NUMBERNUMBER
NUMBER NAME
NAMENAME
NAME ADJUSTMENT
ADJUSTMENTADJUSTMENT
ADJUSTMENT DEFAULT
DEFAULTDEFAULT
DEFAULT
0 LINE VOLTS HIGH, LOW, AUTO AUTO
1 SPEED #1 MIN FRQ - MAX FRQ 20.00 Hz
2 SPEED #2 MIN FRQ - MAX FRQ 20.00 Hz
3 SPEED #3 MIN FRQ - MAX FRQ 20.00 Hz
4 SPEED #4 MIN FRQ - MAX FRQ 20.00 Hz
5 SKIP #1 .00 Hz - MAX FRQ .00 Hz
6 SKIP #2 .00 Hz - MAX FRQ .00 Hz
7 BAND WID .00 - 10.00 Hz 1.00 Hz
8 ACCEL (NOTE 1) 30.0 SEC
9 DECEL (NOTE 1) 30.0 SEC
10 MIN FRQ .00 - MAX FRQ .50 Hz
11 MAX FRQ MIN FRQ - 120.0 Hz (NOTE 2) 60.00 Hz
12 DC BRAKE (NOTE 1) .0 VDC
13 DC TIME .0 - 999.9 SEC .0 SEC
14 DYN BRAKE OFF, ON OFF
16 CURRENT 25 - 180 % (NOTE 3) 180%
17 MOTOR OL 25 - 100 % 100%
18 BASE 20.00 - 360.0 Hz (NOTE 2) 60.00 Hz
19 FX BOOST .0 - 30.0 % (NOTE 1)
20 AC BOOST .0 - 20.0 % 0.00%
NOTE 1: REFER TO SECTION 18.0 - DESCRIPTION OF PARAMETERS.
NOTE 2: MAX LIMIT IS 650 Hz ON UNITS WITH HIGH FREQUENCY SOFTWARE.
NOTE 3: IF LINE VOLTS IS SET TO "LOW" (OR SET TO "AUTO" AND THE INPUT VOLTAGE
IS LOW), THE RANGE IS 25 - 150%.
17.0 PARAMETER MENU
