16.0 PROGRAMMING THE MC1000 DRIVE
16.1 PROGRAMMING THE PARAMETERS
The MC1000 keypad serves two purposes: operating the drive when in the
LOCAL mode, and programming the parameters for particular applications. The
keypad is shown below, along with the display that should appear when the drive
is first powered up:
To program the drive, the PROGRAM mode must be entered by pressing the
PROG/RUN button. If the password protection is disabled, pressing the PROG/
RUN button will result in direct entry into the PROGRAM mode. If the password
protection is enabled, the PASSWORD prompt will appear when an attempt is
made to enter the PROGRAM mode. The PASSWORD prompt appears as
follows:
To enter the password, use the UP and DOWN arrow keys to scroll to the
password value, and then press the ENTER key.
NOTE: The factory default password is 0019.
PASSWORD 0000
CURSOR
PROG
STOP > 20.00 HZ
START
STOP
ENTER
FWD
REV
AUTO
MANRUN
To Next Page
