44
Once the correct password is entered, the PROGRAM mode will be entered and
the first parameter will be displayed, which is Parameter 0 - LINE VOLTS. This
is shown below:
To scroll through the parameters, use the UP and DOWN arrow buttons on the
keypad. When the desired parameter is found, press the ENTER key to shift the
cursor from the parameter name to the parameter value. In this example, the
cursor shifts from LINE VOLTS to AUTO:
The parameter value can then be changed using the UP and DOWN arrow buttons.
If the parameter has a numerical value, the UP arrow will increase the value and the
DOWN arrow will decrease the value. If the parameter has specific choices that
can be selected, the UP and DOWN arrow keys will scroll through the list of
possible settings. When the desired value or option is selected, press the ENTER
key to store the new setting. If the new setting is not ENTERED, it will not take
effect and the old setting will still be valid.
If the PROG/RUN key is pushed while the cursor is highlighting the parameter
value, the value will change back to the original setting (if it had been changed, but
not ENTERED), and the cursor will shift back to the parameter name. Pressing
PROG/RUN again will exit the PROGRAM mode. If the PROGRAM mode is
entered again within two minutes, the last parameter that was viewed, or changed,
will come up on the display. After two minutes has elapsed, the password will
have to be entered again when attempting to access the PROGRAM mode.
LINE VOLTS AUTO
PARAMETER
NAME
PARAMETER
VALUE
CURSOR
LINE VOLTS AUTO
PARAMETER
NAME
PARAMETER
VALUE
CURSOR
