Output Array bytes 0 and 1 Operating Mode Command - continued
Byte Bit Function Value
Switchpad
Type
Action Performed
(Param 51)
7 not used x x none
6 not used x x none
5 not used x x none
4 not used x x none
3 not used x x none
2 not used x x none
Activate the AUXILIARY input.
1 x
This option is enabled by setting parameter 52. Refer to page
17 for more information about setting controller parameters.
1
Auxiliary
Input
1
0 x No change.
1 x
Use the d
efault value of parameter 35 to control the
switchpad and edge detector LEDs. Refer to page 17 for
more info
rmation about setting controller parameters.
Null
Indicator
0
0 x
Use the cu
rrent value of parameter 35 to control the
switchpad and edge detector LEDs. Refer to page 17 for
more info
rmation about setting controller parameters.
The Operating Mode Command bits (output array) can be used alone or in parallel with the
controlle
r’s switchpad and discrete isolated inputs to change the controller’s operating mode. To
change the operating mode, the fieldbus master should set the desired Operating Mode
Command bit high. Once received, the controller will store the new operating mode in memory,
then return an updated Operating Mode Status byte to the fieldbus master (input array). The
fieldbus master should verify that the correct Operating Mode Status bit has changed, then
complete the command by setting all Operating Mode Command bits low. Setting the bits low
allows the controller to accept operating mode inputs from the switchpad and discrete isolated
inputs.
Fieldbus Interface
108
