3-46 Machine Maintenance
Removing the Microphone 0
1. Perform the “Removing the LCD Panel” procedure described on page 3-43.
2. Release the microphone cable from the adhesive tapes securing them.
Figure 3-61. Microphone Adhesive Tapes
3. Gently pry the microphone off the LCD back panel.
Figure 3-62. Microphone
