Machine Maintenance 3-9
Removing the Battery Pack 0
1. Turn the computer over so that the base is facing up.
2. Slide and hold the battery release latch to release the battery pack.
3. Lift the battery pack from its bay.
Figure 3-3. Battery Pack
The battery has been highlighted with the yellow rectangle in Figure 3-3. Detach the
battery and follow local regulations for disposal.
