3-18 Machine Maintenance
Removing the Palmrest Module/Upper Case 0
1. Perform the “External Module Disassembly Process” procedures described on pages 3-8
to 3-12.
2. Remove the seventeen base side screws securing the upper case to the lower case.
Figure 3-16. Upper Case Screws – Base Side
3. Turn the computer over and open the LCD panel.
Table 3-16. Screws
Step Screw Quantity Screw Type
Upper Case Disassembly M2.5 × L5 17
