Heating/Cooling Curves of the Toshiba D-041 anode
FIRMWARE
RXCD board 2,20
RXHVC board 2,14
PLEASE NOTE
Firmware versions maybe periodically updated therefore the versions indicated in the chart above may be different from the versions instal-
led on the unit.
To know the rmware versions installed in your X-MIND unity please follow the instructions in the following chapter “ADVANCED SETTINGS”
of the “X-MIND unity Installation and Maintenance manual”.
DEVICE POWER SUPPLY and ELECTRICAL CLASSIFICATION
Supply voltage 100 V à 240 V
Supply voltage frequency 50/60 Hz
Maximum Line Current
(technique factors that constitute maximum line current condition: 65kV, 7mA, 2s)
8,5 A (@100 V)
Standby current 100 mA
Maximum Adsorbed Power 850 VA
Maximum Rated Power 900 W
Adsorbed Power
(Stand-by mode, not armed)
3 VA
Adsorbed Power
(Armed mode – 240Vac/60Hz)
26 VA
Rated Power @ 0.1s 900 W à 70 kV/6 mA
Fuse (only Line) T10 AH 250 V
Apparent Resistance 0.2 Ω
