Operator’s manual • X-Mind unity • VH • (15) • 09/2017 • NUN0EN010H
ENGLISH
ELECTRICAL CLASSIFICATION (IEC 60601-1)
According to the general safety regulations of IEC 60601-1 2nd and 3rd editions concerning the safety of electro-medical equipment, this
system is classied as:
Protection against electrical shock (insulation class) Class I
Degree of protection against electrical shock (applied part) TYPE B
Use with ammable anaesthetics
Not evaluated for use in presence of ammable anaesthetic mix-
ture with air, oxygen or nitrous oxide
Sterilization and disinfection methods
The device is supplied not sterile and it must not be subjected to
sterilization
Operation mode Continuous operation with intermittent X-ray loading
NFPA 70 Classication Momentary Operation (<5s)
!
WARNING
NEVER CONNECT the X-Mind Unity to the mains without rst checking the voltage setting as indicated on the labels. Incorrect voltage set-
tings will cause irreversible damage to the X-Mind unity electronics.
DEGREE OF PROTECTION PROVIDED BY ENCLOSURES
According to the standard EN 60529, the degree of protection is:
IP20
MECHANICAL DATA
Dimensions Refer to the dedicated annex relevant to the dimensions
Total Weights
24kg / (52.9 lbs) (with horizontal bracket length 1100mm) / (43.3”)
23kg / (50.7 lbs) (with horizontal bracket length 800mm) / (31.4”)
22kg / (48.5 lbs) (with horizontal bracket length 400mm) / (15.7”)
Weight of the Tubehead Assembly 5.5 kg / (12.1 lbs)
Mechanical conguration Wall mounting. Top and Bottom mounting.
