Operator’s manual • X-Mind unity • VH • (15) • 09/2017 • NUN0EN010H
ENGLISH
SIDE VIEW (CLOSED) - TOP MOUNT
D
40cm (16”) bracket 60cm (24”)
80cm (31”) bracket 100cm (39”)
110cm (43”) bracket 130 (51”)
SIDE VIEW (OPEN) - BOTTOM MOUNT
