Acuity Controls GR2400 User Manual

Pg. 6 www.lightingcontrols.com
USER MENU
MANUAL OVERRIDE
REVIEW SCHEDULE
GROUP LOADS
PROGRAM SWITCH
SETUP MENU
SWITCHES PAGE 1-2
#33: Ofce 101
#52: Ofce 102
#53: Ofce 103
#59: Ofce 104
#61: Ofce 105
#61: Ofce 106
#61: Ofce 107
SWITCHES PAGE 2-2
#63: Reception
#64: Photocell North
#65: Photocell West
#66: Master Sw 3
#71: Hallway 100
#72: Hallway 200
#73: Hallway 220
SWI ID64-1 MAINTAIN
EDIT: LCP-1 LOAD-1
SELECT BTN SWI ID#64
PAGE 1-3
T1: TRIGGER 1
T2: TRIGGER 2
T3: TRIGGER 3
T4: TRIGGER 4
T5: TRIGGER 5
T6: TRIGGER 6
BASIC PHOTOCELL SETTINGS
To Start:
1. TAB to start.
2. TAB to Program Switch.
3. ENTER to select.
For Multiple Pages: (more than 7 switches)
1. SCROLL to the correct page.
To Select a Photocell Card:
A Photocell Card is like a digital switch.
1. TAB to the correct Switch ID.
2. ENTER to select.
To Select Trigger:
Each Photocell Card has 14 Triggers, each
of which:
• may control its own set of loads
• may be programmed to switch loads on and
o at levels analogous to foot candles
1. If needed, SCROLL to the correct page for
Triggers higher than T6.
2. TAB to the correct Trigger.
3. ENTER to select.
4. SCROLL to Maintain.
5. ENTER to select the Trigger Level Menu.
PROGRAM SWITCH
PAGE 1-2
#64: Photocell North
MAINTAIN
T1: TRIGGER 1
This indicates Page
1 of 2
If cursor starts here,
you have multiple
pages with switches
on each page. You
may need to navigate
to the correct page.
This indicates you
have selected Switch
ID#64.
To access Triggers
above T6, SCROLL
the correct page
and then TAB to the
correct Trigger.
Select MAINTAIN as
the Control Type*.
Press ENTER to get to
Trigger Level Menu.
(For more than
eight loads, refer
to “Programming
Groups”).
76
