Acuity Controls GR2400 User Manual

LC&D 800.345.4448 Pg. 9
Schedule Type:
• EVERY DAY—7 day
schedule
• Mon-Fri, Sat, Sun
• BY DAY unique for
each day
Trigger Event:
• TIME means a
specic time of day
in hrs./mins.
• “DAWN (or DUSK) +
or -” means minutes
and seconds before/
after dawn or dusk
• NONE means none
This is the summary
of the Monday
Schedule.
This is the Edit
Schedule for Monday.
Link Other Days:
To save programming
time, link other days
using the same
schedule.
SCHEDULE TYPES & TRIGGER EVENTS
1. SCROLL to the desired schedule type.
Every Day (7-day schedule):
1. TAB to ON TIME and SCROLL to select Trigger
Event.
2. TAB to the hour and SCROLL to select.
3. TAB to minutes and SCROLL to select.
Mon-Fri, Sat, Sun:
1. TAB to ON TIME and SCROLL to select Trigger
Event.
2. TAB to the hour and SCROLL to select.
3. TAB to minutes and SCROLL to select.
4. Tab to each day set and repeat.
By Day (unique for each day):
This Schedule Type allows On and O times to
be edited to the nearest second, and allows a
schedule to start and end on specic dates.
1. Tab to desired day and ENTER to edit.
2. TAB to the hour and SCROLL to select.
3. TAB to minutes and SCROLL to select.
4. TAB to seconds and SCROLL to select.
To link other days to this schedule:
1. TAB to Every Day.
2. SCROLL to desired days or day sets and ENTER
to select.
3. EXIT to edit more days.
To select schedule start and stop date.
1. TAB to Jan and SCROLL to select.
2. Repeat to set start and stop dates.
To Exit this Schedule and Add Loads:
1. EXIT when complete.
2. TAB down once to edit the group and add
loads to this schedule (refer to Group Editing
Section).
SCH 1 EXCEPT NONE
EVERY DAY
ON TIME: 09:00 AM
OFF TIME: 05:00 PM
SCH 1 EXCEPT NONE
MONDAY - FRIDAY
ON TIME: 09:00 AM
OFF TIME: 05:00 PM
SAT ON DUSK+0:00
OFF DAWN+0:00
SUN ON NONE
OFF NONE
SCH 1
BY DAY H1 H2
Mo Tu We Th Fr Sa Su
ON TIME: 09:00:00a
OFF TIME: 05:00:00p
from Jan 1 to Dec 31
SCH 1
H1 H2
Mo Tu We Th Fr Sa Su
ON TIME: 09:00:00a
OFF TIME: 05:00:00p
from Jan 1 to Dec 31
ON TIME: 9:00:00 am
OFF TIME: 5:00:00 pm
ADJUST THESE DAYS:
Mon
Every Day
EVERY DAY
TIME:
Mo
Every Day
Jan
79
