Page 28
Setup 4 - Bass Limiter
TRx BRx VRx
TONE RECALL1 TN BL VL EQ
BAL RECALL1 SETUP
VOL RECALL1 LOUDNESS M]
LABELS/AV PL EH [P M]
SPEAKERS BASS ADABUS
LEVELS HDMI THX TURN ON
DELAYS SOLO TEST REVERB
BASS LIMITER [P M]
LIMITER CEILING OFF
BASS LIMITER [P M]
LIMITER CEILING OFF
BASS LIMITER [P M]
LIMITER - 5.O DB
The Suite 7.1 HD provides you with the ability
to engage a Bass Peak Limiter that operates in
a range from 0 dB (decibels) to -24 dB. The
function of the Bass Peak Limiter is to reduce the
possibility of overloading the subwoofer in cases
of extreme volume and/or software that provides
extremely dynamic bass information. If your
subwoofer is capable of providing a large level of
bass without bottoming out, you may not need to
engage the Bass Peak Limiter (leaving it Off). If
however, you play your system at volume levels
that on occasion will cause your subwoofer to play
distorted audio segments, you will wish to engage
the Bass Peak Limiter. The Suite 7.1 HD’s “Out
Of The Box” setup has the Bass Peak Limiter, also
known as the Bass Limiter, set to OFF.
When setting Bass Peak Limiter using the PC
program, select the side THEATER tab, the PRO
SETUP top tab and then the 4-BASS sub tab.
Here you can increase (UP) or decrease (DN) the
limiter level in dBs. All changes occur in real-time
(instantly).
From the front of the Suite 7.1 HD, while in the
setup mode, use the Mode knob to navigate to
the word SETUP and press the Mode knob. On
the page that features LABELS/AV in the top left
corner, use the Mode knob to navigate to the
BASS option and press the Mode knob.
You are now on the Bass Peak Limiter page with
the cursor ashing on the L in LIMITER. To en-
gage and/or alter the Limiter, turn the Input knob
accordingly. The Bass Peak Limiter range is OFF
(0 dB) to -24 dB.
To return to the previous page, turn the Mode
knob to the letter P (previous) and press the
Mode knob.
To exit the Setup Mode entirely, navigate to the
letter M (main) and press the Mode knob.
