ADDER AdderLink XDIP User Manual

20
INSTALLATIONCONFIGURATIONOPERATION
FURTHER
INFORMATION
INDEX
Name and Description
These tags are useful for differentiation purposes when numerous nodes are being used.
Use the Receiver Name and Receiver Description elds to change them.
Time and Date
These are shown only if access to an NTP server is available. The current time and date
are frozen within this page and do not automatically update.
Serial Number
Shows the unique hardware identity applied to this node.
MAC Address
Shows the unique network identity applied to this node.
Software Version
Shows the current main version of internal rmware.
Receiver Name and Receiver Description
These elds allow you to change the name and description tags for this node.
Admin Password
Allows you to change the administration password (that protects this menu).
ADMIN - General Settings
Receiver 1
Receiver General Settings
General
Name Description
Uptime Serial Number
MACAddress
Receiver Name
Receiver Description
Admin password
SoftwareVersion
Node Name Description
25 mins 1701A0000001
00:0F:58:02:DF:3A 1.00
OSD Settings
Setup Channels
Manage Ports
Advanced
Software Upgrade
RECEIVER
Review this node’s general information and update its details.
ApplyCancel
Change
Node Name
Description
Time Date10:37:28 (UTC) Wed 12 Jul 2017
ADMIN MENUS
Once an AdderLink XDIP installation has undergone its initial conguration, if necessary
you can make further alterations using the Admin menu. An Admin menu is accessible
via each receiver, wherein changes can be made to that receiver and/or any of the linked
transmitters.
To enter the Admin menu
1 From any connected receiver node, enter the receiver’s OSD: Press CTRL + ALT + C*
2 Click the icon in the top right corner to display the receiver’s General Settings
page (see below), you will be requested to enter an admin password.
 Most pages have an Apply button which must be clicked after making changes in order
to save them. Alternatively, you can select the Cancel button to exit a page without
retaining your latest changes.
 To exit any Admin page, click the icon in the top right corner.
To view the conguration details for a transmitter node, see page 26.
* Note: The standard hotkey combinations can be changed, see page 21
Receiver node settings
General Settings page
When you enter the Admin Menu, the rst page to be displayed will be the General
Settings page for the receiver to which you are directly connected. This page provides
basic information for this node:
Receiver node
General Settings this page
OSD Settings page 21
Setup Channels page 26
Manage Ports page 22
Advanced page 23
Software Upgrade page 25
Transmitter node
General Settings page 26
Manage Ports page 27
Advanced page 28
Software Upgrade page 29
The various parts of the Admin menu are detailed on the following pages:

ADDER AdderLink XDIP Specifications

General

Type	Transmitter & receiver
Material	Metal
Certification	CE, FCC
Product color	Black
LED indicators	Link, Power, USB, Video
Cable types supported	Cat5, Cat6, Cat7
Connectivity technology	Wired
Maximum transfer distance	100 m
Maximum digital resolution	1920 x 1200 pixels
Operating temperature (T-T)	0 - 40 °C
Input current	0.7 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output voltage	12 V
USB 2.0 ports quantity	4
Receiver local video port type	HDMI
RJ-45 ports quantity (receiver)	1
Receiver local keyboard/mouse port type	USB
Weight	600 g
Dimensions (WxDxH)	169 x 120 x 31 mm
Package depth	290 mm
Package width	248 mm
Package height	55 mm
Cables included	Audio (3.5mm), HDMI, USB
AC adapter included	Yes
Harmonized System (HS) code	84733080
