ADDER AdderLink XDIP User Manual

21
INSTALLATIONCONFIGURATIONOPERATION
FURTHER
INFORMATION
INDEX
OSD Settings page
This page contains all settings related directly to the On Screen Display menu:
Language
Determines the language used for all OSD menu text. Options are: English, Français,
Español and Deutsch.
Keyboard
Determines the layout styles used for the keyboard attached to the receiver. Options
include: gb, us, fr, de and es.
OSD Mouse Launch
Allows you to optionally choose mouse button combinations that will launch the OSD
menu.
Hotkeys
Allows you to change the two main hotkeys which are used to indicate that you wish to
communicate with the receiver itself rather than any of the connected computers.
Next and Previous Channel Hotkey
Allows you to dene keyboard buttons which, when used together with the chosen main
hotkeys, will move to the next or previous channel (based on the receiver node’s channel
list). Options include Tab, Backspace, Enter, Space, the arrow keys or any keyboard Letter
(which needs to be dened in the white box on the right). Note: If the Letter option is
selected,butnoletterisdenedwithinthewhitebox,thenthefunctionalityisdisabled.
OSD Hotkey
Denes the key which, when used together with the chosen main hotkeys, will display the
OSD menu.
Disconnect Hotkey
Denes the key which, when used together with the chosen main hotkeys, will
disconnect the receiver from the currently chosen channel.
OSD Timeout
Denes the period of inactivity (in whole minutes) that should pass before the OSD
menu is automatically exited (0 disables the OSD timeout). Note: The automatic timeout
fromtheAdminmenuisxedat15minutes.
ADMIN - OSD Settings
Receiver 1
Configure OSD Settings
General
Language
Keyboard
OSD Mouse Launch
Hotkeys
Next Channel Hotkey
Previous Channel Hotkey
OSD Hotkey
Disconnect Hotkey
OSDTimeout
OSD Settings
Setup Channels
Manage Ports
Advanced
Software Upgrade
RECEIVER
Update this node’s OSD timeout and hotkeys.
ApplyCancel
English
gb
None
Left Ctrl Left Alt
Letter
Letter
Left Ctrl + Left Alt +
Left Ctrl + Left Alt +
Left Ctrl + Left Alt +
Left Ctrl + Left Alt + x
c
min1

ADDER AdderLink XDIP Specifications

General

Type	Transmitter & receiver
Material	Metal
Certification	CE, FCC
Product color	Black
LED indicators	Link, Power, USB, Video
Cable types supported	Cat5, Cat6, Cat7
Connectivity technology	Wired
Maximum transfer distance	100 m
Maximum digital resolution	1920 x 1200 pixels
Operating temperature (T-T)	0 - 40 °C
Input current	0.7 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output voltage	12 V
USB 2.0 ports quantity	4
Receiver local video port type	HDMI
RJ-45 ports quantity (receiver)	1
Receiver local keyboard/mouse port type	USB
Weight	600 g
Dimensions (WxDxH)	169 x 120 x 31 mm
Package depth	290 mm
Package width	248 mm
Package height	55 mm
Cables included	Audio (3.5mm), HDMI, USB
AC adapter included	Yes
Harmonized System (HS) code	84733080
