ADDER AdderLink XDIP User Manual

22
INSTALLATIONCONFIGURATIONOPERATION
FURTHER
INFORMATION
INDEX
Monitor Details
Manufacturer: DEL
Model ID: 61462
Serial Number: F525M098046L
Manufacture Date (week/year): 37/2010
EDID Version: 1.3
Preferred Resolution: 1920x1080p@60Hz 148.50MHz
1920x1080p@60Hz 148.50MHz
1152x864p@75Hz 108.00MHz
1280x1024p@60Hz 108.00MHz
1600x900p@60Hz 97.75MHz
1920x1080p@60Hz 138.50MHz
720x400p@70Hz 28.32MHz
EDID Details
OK
Manage Ports page
All settings within these pages relate to the video monitor, USB devices and/or local
computer that are connected to this receiver node.
Computer Name
Computer Description
Computer Name
Description
ADMIN - Port Settings
Receiver 1
General
OSD Settings
Setup Channels
Manage Ports
Advanced
Software Upgrade
RECEIVER
Review this node’s local computer, USB and video por
t information and change its settings.
ApplyCancel
Local Video USB
ADMIN - Port Settings
Receiver 1
General
OSD Settings
Setup Channels
Manage Ports
Advanced
Software Upgrade
RECEIVER
Review this node’s local computer,USB and video port information and change its settings.
Apply
Details
Cancel
Local VideoUSB
Connected Monitor
Choose the video EDID that will be
presented to the attached computer
DEL 61462
Connected Monitor
Connected Monitor
Lists the basic details for the monitor connected to the
console video output of this receiver node. Click on
the Details button to view more information about the
connected video monitor:
Connected Devices
Lists the USB devices which are currently connected
to this receiver node. Click the Details button to view
more information about the device.
Computer Name and Computer Description
These tags are useful for differentiation purposes when
numerous nodes are being used. These elds allow you to
change the name and description tags for the computer that
is directly attached to this receiver node (shown on the OSD
as channel 0).
Choose the video EDID....
Allows you to choose to rely upon the Automatic EDID
conguration for the connected monitor or to manually
select one of the listed modes.
ADMIN - Port Settings
Receiver 1
General
OSD Settings
Setup Channels
Manage Ports
Advanced
Software Upgrade
RECEIVER
Review this node’s local computer, USB and video port information and change its settings.
Apply
Details
Details
Details
Cancel
Local Video USB
Connected Devices ABC Ltd
HAL Inc.
XYZ
USB Hub
USB Keyboard
USB Mouse

ADDER AdderLink XDIP Specifications

General

Type	Transmitter & receiver
Material	Metal
Certification	CE, FCC
Product color	Black
LED indicators	Link, Power, USB, Video
Cable types supported	Cat5, Cat6, Cat7
Connectivity technology	Wired
Maximum transfer distance	100 m
Maximum digital resolution	1920 x 1200 pixels
Operating temperature (T-T)	0 - 40 °C
Input current	0.7 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output voltage	12 V
USB 2.0 ports quantity	4
Receiver local video port type	HDMI
RJ-45 ports quantity (receiver)	1
Receiver local keyboard/mouse port type	USB
Weight	600 g
Dimensions (WxDxH)	169 x 120 x 31 mm
Package depth	290 mm
Package width	248 mm
Package height	55 mm
Cables included	Audio (3.5mm), HDMI, USB
AC adapter included	Yes
Harmonized System (HS) code	84733080
