Version 15.0 AF-5000 Series Pilot Guide 2
AF-5000 Series Post Installation Check
CAUTION: Do not fly the aircraft until the following check list has been completed.
Never Power the system with an automotive battery charger and the aircraft battery
disconnected.
Before Power is applied for the First Time
✓ Screen mounted following the installation manual
✓ ADAHRS mounted
✓ Screen case has been properly grounded using case screw
✓ Wiring harness is properly connected to screen
✓ Verify relay protection diodes are installed on all large aircraft relays (Master, Starter)
✓ Pitot/Static and AOA plumbing is secured to the correct ADAHRS ports
✓ Trim Servo indication wires are connected per the installation manual wiring diagram
✓ Verify Aircraft battery + and – are correct
Applying Power for the First Time
✓ Turn on aircraft Master Switch power and power on the screens
✓ Verify the unit powers on
✓ Configure Advanced SV-Network on PFD EFIS
o [SET] > [CAL] > 2. Advanced SV-Network
o [SCAN] Network
o [UPDT] device software
✓ Configure your Serial Ports based on devices connected
✓ Configure your GPS/NAV Settings based on Serial Port selection
✓ Configure AirData, AHRS and EMS Type in CAL > ADMIN Settings
✓ Following the installation manual, calibrate the Fuel Tanks
✓ Following the installation manual, calibrate all trim and flap position sensors
✓ Set the airspeed V speeds based on your aircraft manufacturers
recommendations.
✓ Set all engine temperatures/limits based on your engine manufacturers
recommendations
✓ Set fuel tank, fuel pressure, fuel pressure, oil temperature, and oil pressure warning
parameters
✓ Verify all GPS and NAV sources are properly communicating with the EFIS.
✓ Set the clock time-zone offset
