Advanced Motion Controls 12A8 - Mounting; Mounting Card

MNALAZIN-02 23
Integration in the Servo System / Mounting
Mounting
ThissectionprovidesinstructionsandinformationonthedifferentwaystomountanAZservo
drivetoaPCBboard.
FIGURE 3.3
MC1XAZ01 and AZ20 Drive Mounted on MC1XAZ01 and Phoenix Contact DIN Tray (mating Connectors shown are
included with MC1XAZ01, DIN tray shown for reference only, available from Phoenix Contact)
Mounting Card
AZservodrivesaredesignedtointerfacedirectlywiththeADVANCEDMotionControls
mountingcardMC1XAZ01.Pinouts,dimensions,andorderinginformationforthemounting
cardareobtainableontheMC1XAZ01datasheet,availablefordownloadatwww.a‐m‐c.com.
TheMC1XAZ01isdesignedforeasymountingandinstallationonastandardDIN‐railtray,
availablefromPhoenixContact(www.phoenixcontact.com,partnumber
2952020/UM72/10.16/GN6021).TheMC1XAZ01isshippedwiththefollowingincluded
connectors:
TABLE 3.1
MC1XAZ01 Connectors
Description Qty. Included Manufacturer and Part Number
3-position 5.08mm spaced plug terminal 1 Phoenix Contact: 1757022
4-position 5.08mm spaced plug terminal 1 Phoenix Contact: 1757035
8-position 3.5mm spaced plug terminal 2 Phoenix Contact: 1840421
MC1XAZ01 Connectors
Inaddition,usersmaydesigntheirownmountingcardtomatewithanAZservodrive.For
moreinformationondesigninganAZcompatiblePCBinterfacecard,see“PCBDesign”on
page26.
