93 ADAM-4000 Series User Manual
Chapter 4 Command Set
$AA6 Read Channel Status
Get the enable/disable status of all
channels in an analog module
5-18
$AA0 Span Calibration
Calibrates an analog input module to
correct for gain errors
5-19
$AA1 Offset Calibration
Calibrates an analog input module to
correct for offset errors
5-20
#**
Synchronized
Sampling
Orders all analog input modules to
sample their input values and store
them in special registers
5-21
$AA4
Read Synchronized
Data
Returns the value that was stored in
the specified module's register after
the #** command
5-22
$AAB Channel Diagnose
Diagnose channel status in over
range, under range, and wire opening
5-24
$AA0Ci
Single Channel
Span Calibration
Calibrates a specified channel to cor-
rect for gain errors
5-27
$AA1Ci
Single Channel
Offset Calibration
Calibrates a specified channel to cor-
rect for offset errors
5-28
$AA7CiRrr
Single Channel
Range Configuration
Configure the input type and range of
the specified channel in an analog
input module
5-29
$AA8Ci
Read Single Chan-
nel Range Configura-
tion
Get the input type and range of the
specified channel in an analog input
module
5-30
$AAXnnnn
Watchdog Timer
Setting
Set communication WDT cycle time
from 0000 ~ 9999 (unit: 0.1 second. if
value is 0000, the communication
WDT function will be disable)
5-31
$AAY
Read Watchdog
Timer Setting
Read the cycle time setting of com-
munication WDT
5-32
$AAS0 Internal Calibration
Internal self-calibration for offset and
gain errors
5-33
$AAS0
Reload default cali-
brating parameter
Reload factory default calibrating
parameter to overwrite current cali-
brating parameter
5-34
Table 4.6: ADAM-4016 Command Table
Command Syntax Command Name Command Description Page No.
%AANNTTCCFF Configuration
Sets the address, input range, baud
rate, data format, checksum status,
and/or integration time for a specified
analog input module
5-4
$AA2 Configuration Status
Returns the configuration parame-
ters for the specified analog input
module
5-10
$AAF
Read Firmware
Version
Return the firmware version code
from the specified analog input mod-
ule
5-12
$AAM Read Module Name
Return the module name from the
specified analog input module
5-13
Table 4.5: ADAM-4015/ADAM-4015T Command Table
