291 ADAM-4000 Series User Manual
Appendix A Technical Specifications
A.6 ADAM-4017/4017+ 8-channel Analog Input
Module
Table A.8: ADAM-4017/4017+ Specifications
AI channel number
ADAM-4017: 6 differential and 2 single-ended
ADAM-4017+: 8 differential
Input type mV, V and mA
Input range
ADAM-4017:
±150 mV, ±500 mV, ±1 V, ±5 V, ±10 V and ±20 mA
ADAM-4017+:
±150 mV, ±500 mV, ±1 V, ±5 V, ±10 V, ±20 mA and 4~20 mA
Output
speed (bps)
Maximum distance
RS-485 (2-wire)
1200, 2400, 4800, 9600, 19.2K, 38.4K, 57.6K, 115.2K
4000 ft. (1200 m)
Isolation voltage
3000 V
DC
Resolution 16-bit
Sampling rate 10 samples/second (total)
Bandwidth 13.1 Hz
Accuracy ±0.1% or better
Zero drift ±6 V/°C
Span drift ±25 ppm/°C
CMR @ 50/60 Hz 120 dB
NMR @ 50/60 Hz 100 dB
Input impedance Voltage: 20 M, Current: 120
Support protocol
ADAM ASCII (ADAM-4017 & 4107+)
MODBUS/RTU (ADAM-4017+ only)
Watchdog timer
ADAM-4017: System (1.6 second)
ADAM-4017+: System (1.6 second) and communication
Power requirements
+10 to +30 V
DC
(non-regulated)
Power consumption
1.2 W @ 24 V
DC
